Automatic Valve KNIFE GATE SOLENOID VLV L2004ABWW-DBCSS
$ 727
Part No: L2004ABWW-DBCSS
-
5/2-way directional valve for general automation
-
Double solenoid actuation with detent return
-
Handles 35–150 psig; ideal for knife gate valve control
-
Rugged aluminum construction with Buna-N seals
-
Compact inline or manifold mounting design
Description
Specifications
| Specification | Details |
|---|---|
| Manufacturer | Automatic Valve |
| Part Number | L2004ABWW-DBCSS |
| Valve Type | Directional Control Valve |
| Valve Function | 5/2-Way, Double Solenoid |
| Series | L20 |
| Actuation | Electrical |
| Voltage | 240 V AC |
| Power Consumption | 6.8 VA |
| Return Type | Detented |
| Port Size | 3/8 |
| Port Thread | NPT |
| Mounting | Inline / Manifold (Bottom) |
| Body Material | Aluminum |
| Spool Material | Aluminum |
| Seal Material | Buna-N |
| Operating Pressure | 35 to 150 psig (2.4 to 10.3 bar) |
| External Pilot Supply | 35 to 150 psig (2.4 to 10.3 bar) |
| Flow Media | Filtered Air |
| Flow Capacity | 1.8 Cv (1800 Nl/min) |
| Pilot Supply | Internal |
| Duty Rating | Continuous Duty |
| Dustproof Feature | Not Included |
| Manual Override | Push Non-Locking |
| Connection Type | DIN EN 175301-803 Form B |
| Temperature Range | -20 to 123 °F (-29 to 50 °C) |
| Weight | 0.9 lb (0.5 kg) |
| Dimensions (L x W x H) | 8.55″ x 1.94″ x 0.5″ (217.1 × 49.2 × 12.7 mm) |
