SCHNEIDER ELECTRIC Circuit Breaker SNS100N/TM63D
Part No: SNS100N/TM63D
SCHNEIDER ELECTRIC 3P Circuit Breaker 750V 63A TM63D
This high-performance circuit breaker from SCHNEIDER ELECTRIC, Part No: SNS100N/TM63D, is rated at 750V, 3-pole, and 63A. Designed for vacuum station operations, it includes a thermal magnetic TM63D trip unit, with an IR adjustable range of 0.8–1.0 x 63A and instantaneous (IM) setting of 500A. Ideal for precise protection in demanding power distribution systems.
Description
SCHNEIDER ELECTRIC Circuit Breaker SNS100N/TM63D
750V, 3-Pole, 63A, Thermal Magnetic Circuit Breaker for Vacuum Station Applications – IM 500A, IR Adjustable 0.8–1.0 x In
| Part Number | SNS100N/TM63D |
|---|---|
| Brand | SCHNEIDER ELECTRIC |
| Product Type | Circuit Breaker (Thermal Magnetic) |
| Voltage Rating | 750V AC |
| Current Rating | 63A |
| Poles | 3 Pole |
| Frequency | 50/60 Hz |
| Application | Vacuum Station Power Distribution |
| Trip Unit Type | TM63D (Thermal Magnetic) |
| IR Setting | Adjustable 0.8 to 1.0 × 63A |
| IM Setting | 500A Instantaneous |
| Interrupt Capacity | Standard (exact value not specified, typically high for SNS series) |
| Standards | QA/QC Certification Required (Level A, C) |
| Catalog/Ref. | CATA:A |
