STI-USA Handheld Vibration Meter Kit CMCP620VT
$ 5,975
Lead Time
1–2 Weeks
Ex-Works
UAE
Shipping
Standard domestic shipping within the USA at a flat rate of $50.
Get a quote for international shipment.
Key Features
-
Portable combined vibration and temperature measurement in one kit for field diagnostics
-
Comprehensive multi-parameter vibration assessment: acceleration, velocity, displacement, and bearing condition
-
Optional non-contact infrared temperature sensing for surface temperature evaluation
-
Rechargeable battery with extended runtime and dual charging options (AC and vehicle)
-
Quick-connect magnetic base and probe accessories for flexible application on rotating machinery
STI-USA Handheld Vibration Meter Kit (Vibration & Temperature) CMCP620VT
The STI-USA CMCP620VT is an industrial handheld vibration meter and temperature monitoring kit designed for predictive maintenance, condition monitoring, and machinery health assessment across industrial environments. This battery-powered, portable unit enables field technicians and maintenance engineers to measure vibration parameters (acceleration, velocity, displacement) and surface temperature quickly and accurately. With ISO-compliant alarm checks and robust construction, it’s ideal for routine inspection of rotating and critical equipment to prevent failures and optimize uptime.
Specifications
| Specification | Details |
|---|---|
| Manufacturer | STI-USA |
| Product Type | Handheld Vibration & Temperature Meter Kit |
| Part Number | CMCP620VT |
| Function | Vibration measurement (acceleration, velocity, displacement) and temperature |
| Vibration Sensor | 100 mV/g constant current accelerometer |
| Frequency Response | Acceleration: 5 Hz – 12 kHz; Velocity: 10 Hz – 1 kHz; Displacement: 5 Hz – 1 kHz; Bearing: 1 kHz – 12 kHz |
| Temperature Range | –20.6 °C to 121.1 °C (optional infrared sensor) |
| Display | LCD display with hold function |
| Battery | Rechargeable lithium battery (48 hr operation) with AC & car charger |
| Casing/Protection | Portable handheld enclosure, IP 54 sealed |
| Mounting Accessories | Magnetic mount, 75 mm spike, 0.8 m cable |
| Compliance | ISO 2954, ISO 20816-3, ISO 10816-3 |
| Weight | Approx. 1.25 kg (full kit) |
| Included in Kit | Handheld meter, temp sensor & probe, magnetic mount, spike, cables, chargers, carry case |
