Festo Precision Pressure Regulator LRP-1/4-10
$ 60
LRP-1/4-10
-
High-precision diaphragm control valve for stable pressure regulation
-
Supports both compressed air and inert gases
-
Flow rate of 2300 l/min with G1/4 connections
-
Secondary venting for consistent output pressure
-
Versatile mounting options for flexible installation
Festo Precision Pressure Regulator LRP-1/4-10
The Festo LRP-1/4-10 is a piloted precision diaphragm control valve designed for highly accurate pressure regulation in pneumatic systems. With a constant output pressure and secondary venting capability, it ensures stable performance even under fluctuating inlet pressures. This precision regulator supports both compressed air and inert gases, delivering a standard nominal flow rate of 2300 l/min with G1/4 connections. Its robust aluminum housing, NBR seals, and RoHS compliance make it suitable for a wide range of industrial applications. The LRP-1/4-10 offers versatile mounting options, including front panel and in-line installation, for seamless integration into control systems.
Specifications
| Model | LRP-1/4-10 |
|---|---|
| Actuator Lock | Rotary knob with detent |
| Mounting Position | Optional |
| Design | Piloted precision diaphragm control valve |
| Controller Function | Output pressure constant, with secondary venting |
| Symbol | 00991540 |
| Pressure Gauge/Display Port | Prepared for G1/8 |
| Operating Pressure | 1–12 bar (0.1–1.2 MPa) |
| Pressure Regulation Range | 0.1–10 bar |
| Inlet Pressure | 1–12 bar |
| Max. Pressure Hysteresis | 0.02 bar |
| Standard Nominal Flow Rate | 2300 l/min (DIN 1343) |
| Operating Medium | Compressed air ISO 8573-1:2010 [7:4:4], inert gases |
| Lubrication | Not possible |
| Conformity | VDMA24364-B1/B2-L |
| Media Temperature | -10 to +60 °C |
| Ambient Temperature | -10 to +60 °C |
| Product Weight | 310 g |
| Mounting Type | Front panel mounting, in-line installation |
| Pneumatic Connection Port 1 | G1/4 |
| Pneumatic Connection Port 2 | G1/4 |
| Material (Seals) | NBR |
| Material (Housing) | Aluminium |
| Compliance | RoHS |
