Festo Solenoid Valve 5/2-Way Monostable MFH-5-1/4-B
$ 60
MFH-5-1/4-B
-
5/2-way monostable solenoid valve for precise pneumatic control
-
High flow rate of 1300 l/min with G1/4 connections
-
Mechanical spring reset and internal pilot air supply
-
Robust die-cast aluminum housing with soft sealing principle
-
Flexible mounting options for easy installation
Festo Solenoid Valve 5/2-Way Monostable MFH-5-1/4-B
The Festo MFH-5-1/4-B is a high-performance 5/2-way solenoid valve with a monostable design, suitable for reliable pneumatic control in industrial automation systems. Built with a robust die-cast aluminum housing and soft sealing principle, it delivers consistent performance in demanding environments. With a nominal flow rate of 1300 l/min, G1/4 pneumatic ports, and an operating pressure range from 2 to 10 bar, this valve ensures efficient and precise control of pneumatic actuators. It features a mechanical spring reset, pilot actuation, and internal pilot air supply for optimal response times. The MFH-5-1/4-B offers flexible mounting options and meets RoHS compliance, making it a dependable choice for various pneumatic applications.
Specifications
| Model | MFH-5-1/4-B |
|---|---|
| Valve Function | 5/2-way, monostable |
| Type of Actuation | Electric |
| Construction Width | 32 mm |
| Standard Nominal Flow Rate | 1300 l/min (DIN 1343) |
| Pneumatic Working Port | G1/4 |
| Operating Pressure | 2–10 bar (0.2–1 MPa) |
| Design | Poppet seat |
| Type of Reset | Mechanical spring |
| Nominal Size | 7 mm |
| Exhaust-Air Function | With flow control option |
| Sealing Principle | Soft |
| Mounting Position | Optional |
| Manual Override | Non-detenting |
| Type of Piloting | Pilot actuated |
| Pilot Air Supply | Internal |
| Flow Direction | Non-reversible |
| Max. Switching Frequency | 3 Hz |
| Switching Time On | 12 ms |
| Switching Time Off | 36 ms |
| Operating Medium | Compressed air ISO 8573-1:2010 [7:4:4] |
| Corrosion Resistance Class | CRC 1 (Low corrosion stress) |
| Storage Temperature | -40 to +60 °C |
| Media Temperature | -10 to +60 °C |
| Ambient Temperature | -5 to +40 °C |
| Product Weight | 300 g |
| Electrical Connection | Via F coil (ordered separately) |
| Mounting | On PR rail or with through-hole |
| Pilot Exhaust Port 84 | M5 |
| Pneumatic Connections | Ports 1, 2, 3, 4, 5: G1/4 |
| Material (Seals) | NBR, TPE-U(PU) |
| Material (Housing) | Die-cast aluminum |
| Compliance | RoHS |
