LE1 OEM PRESSURE TRANSMITTER LE10150 – 30″/0/150 PSI

Part No: LE10150
LE1 OEM PRESSURE TRANSMITTER 30″/0/150 PSI Featuring a durable stainless steel design, high-precision ceramic sensor, and an accuracy of ±0.5%, this versatile transmitter is ideal for pump monitoring, HVAC, and compressor applications, with IP65 and IP67 ratings and a 5-year warranty.

Add to Wishlist
Add to Wishlist
Category:
Trust Badge Image

Description



Feature Details
Product Type LE1 OEM Pressure Transmitter
Certification CE, RoHS
Construction Compact stainless steel construction with ceramic sensor
Pressure Range Available ranges include Vac up to 8,700 psi (600 bar)
Connections Wide range of mechanical and electrical connections
Accuracy ±0.5% accuracy (±1% for pressures ≤45 psi)
Enclosure Rating IP65 and IP67
Warranty 5-year warranty
Applications Suitable for a variety of applications including pump and compressor monitoring, refrigeration, and HVAC
Output Signal Standard 2-wire: 4-20 mA / Vs = 12-30 Vdc
Optional 3-wire: 0.5-4.5 Vdc / Vs = 10-30 Vdc
Response Time <10 ms
Insulation >100 MΩ @ 50V
Permissible Temperatures Operating: -40°F to 212°F (-40°C to 100°C)
Compensating: 14°F to 176°F (-10°C to 80°C)
Pressure Port / Housing 304 SS
Wetted Parts Diaphragm: Ceramic (up to 2,900 psi)
Seals: NBR, Diaphragm: silicone (over 3,000 psi)
Current Consumption 2-wire: 25 mA max
3-wire voltage: 5 mA (short-circuit current 20 mA)
EMC EMI: EN50087-1/-2
EMS: EN50082-2
Stability Vibration: 10 g / 5 Hz to 200 Hz
Shock: 20 g / 11 ms
Operation Life 2 million cycles
Approval CE, RoHS
