OMRON Multifunction Timer H3CR-A AC24-48/DC12-48 H3CR8091B
$ 110
Lead Time: 1 Week
Shipping:
Free shipping on orders over $199 within the USA.
Get a quote for international shipping.
H3CR8091B
-
Multifunction timer with DPDT contacts
-
Wide time range: 0.05 seconds to 300 hours
-
Compact 48×48 mm housing with 11-pin plug-in base
-
Reliable performance under varying voltage and temperature conditions
OMRON Multifunction Timer H3CR-A AC24-48/DC12-48 H3CR8091B
The OMRON H3CR-A AC24-48/DC12-48 H3CR8091B is a multifunction plug-in timer designed for precision, durability, and flexibility in automation systems. With an 11-pin DPDT output, compact DIN 48 x 48 mm design, and a wide timing range from 0.05 seconds to 300 hours, it ensures reliable control in both industrial and commercial applications.
Specifications
| Specification | Details |
|---|---|
| Reference | H3CR-A AC24-48/DC12-48 |
| Code | H3CR8091B |
| Catalog Number | H3CRAAC2448DC1248OMI |
| Manufacturer | OMRON |
| Product Type | Multifunction Timer |
| Output Contacts | DPDT |
| Contact Rating | 5 A |
| Mounting Type | Plug-in, 11-pin |
| Dimensions | 48×48×66.6 mm |
| Operating Voltage | 24–48 VAC, 12–48 VDC |
| Timing Range | 0.05 s to 300 h |
| Ambient Temperature | -10 to 55°C operating, -25 to 65°C storage |
| Degree of Protection | IP40 (panel surface) |
| Weight | Approx. 90 g |
