SANDPIPER Pneumatic Diaphragm Pump ½” S05 PP/TF
$ 2,210
Part No: S05 PP/TF
-
½” AODD pump with polypropylene body and pneumatic drive
-
Handles abrasive fluids and small suspended solids
-
ESADS+ allows fast, in-line air valve maintenance
-
Compact and portable for industrial and commercial use
Description
SANDPIPER Pneumatic Diaphragm Pump ½” S05 PP/TF
The SANDPIPER S05 PP/TF is a compact, air-operated double diaphragm (AODD) pump built for durability and versatility. With a ½” port size and polypropylene housing, it is ideal for handling abrasive fluids and suspended solids across multiple industries. The ESADS+ air distribution system allows in-line serviceability without pump removal—making it one of the most maintainable pumps in its class.
| Model | S05 PP/TF |
|---|---|
| Part Number | S05 PP/TF |
| Pump Type | Air-Operated Double Diaphragm (AODD) |
| Drive Type | Pneumatic |
| Port Size | ½” NPT (Internal) or ½” BSP (Tapered) |
| Material | Polypropylene (PP) |
| Capacity | 0 to 15 gpm (56 lpm) |
| Max Operating Pressure | 125 psi (8.6 bar) |
| Head Capacity | Up to 298 ft. (86 meters) |
| Solids Handling | Up to 0.125″ (3 mm) |
| Displacement per Stroke | 0.026 gal (0.098 liters) |
| Valve Type | No-lube, no-stall air distribution |
| Serviceability | ESADS+ system, 5-minute access |
| Weight | Approx. 15 lbs (7 kg) |
