Weidmüller Relay 24V DC 4CO DRM570024LD 7760056105
$ 99
Part No: DRM570024LD
-
4 CO relay with 24 V DC coil and plug-in terminals
-
AgNi flash gold-plated contacts for high reliability
-
Green LED and free-wheeling diode integrated
-
IP20 rated, RoHS & REACH compliant industrial relay
Description
Weidmüller Relay 24V DC 4CO DRM570024LD 7760056105
The Weidmüller DRM570024LD is a compact industrial relay designed for reliable switching in control systems. It features 4 changeover (CO) contacts, a 24 V DC coil, and plug-in connection for easy integration. The AgNi gold-flash contacts ensure long-lasting performance even in demanding environments, with high electrical endurance and multiple safety certifications.
| Model | DRM570024LD |
|---|---|
| Part Number | 7760056105 |
| Series | D-Series DRM |
| Coil Voltage | 24 V DC |
| Coil Current | 37.8 mA |
| Power Rating | 0.9 W |
| Coil Resistance | 630 Ω ±10% |
| Contacts | 4 CO (Changeover), AgNi gold flash |
| Continuous Current | 5 A |
| Switching Voltage | 250 V AC (Max) |
| Max Switching Capacity (AC) | 1250 VA (resistive) |
| Max Switching Capacity (DC) | 120 W @ 24 V |
| Min. Switching Power | 10 mA @ 12 V, 100 mA @ 5 V |
| Inrush Current | 10 A / 50 ms |
| Switching Delay | < 20 ms (on/off) |
| Mechanical Life | 20 million cycles |
| Status Indicator | Green LED |
| Protective Circuit | Free-wheeling diode |
| Terminal Type | Plug-in connection |
| Housing Color | Transparent |
| IP Rating | IP20 |
| Certifications | cURus (E312083), RoHS, REACH compliant |
| Flammability Rating | V-2 (cover), V-0 (baseplate), HB (indicator) |
