VACORDA Metal Rotor Flowmeter with HART Output – SS316L, DN 80 PN 16
$ 1,820
VACORDA Metal Rotor Flowmeter with HART Output – SS316L, DN 80 PN 16
A stainless‑steel metal rotor flowmeter built for precision gas measurement under standard conditions. This VACORDA model handles inert gas at densities around 1.337 kg/m³, with a flow range up to 280 Nm³/h. Suitable for applications at atmospheric to moderate pressures (design pressure up to 16 bar) and temperatures up to 120 °C. It features a 4‑20 mA + HART output via an M20 electrical connector, LCD display, and a robust IP65 enclosure — ideal for industrial installations.
| Specification | Details |
|---|---|
| Brand | VACORDA |
| Product Type | Metal Rotor Flowmeter |
| Flow Direction | Left in → Right out |
| Media | Inert Gas |
| Fluid Density | 1.337 kg/m³ |
| Operating Pressure | Atmospheric |
| Design Pressure | Up to 16 bar |
| Temperature Range | 0–120 °C |
| Flow Rate | 0–280 Nm³/h |
| Process Connection | EN 1092‑1 DN 80 PN 16 RF, SS316L |
| Wetted / Body Material | SS316L |
| Output Signal | 4–20 mA with HART + LCD Display |
| Electrical Connector | M20 × 1.5 |
| Supply Voltage | 24 VDC |
| Accuracy | ± 1.5% |
| Protection Rating | IP65 |
VACORDA Metal Rotor Flowmeter with HART Output – SS316L, DN 80 PN 16
A stainless‑steel metal rotor flowmeter built for precision gas measurement under standard conditions. This VACORDA model handles inert gas at densities around 1.337 kg/m³, with a flow range up to 280 Nm³/h. Suitable for applications at atmospheric to moderate pressures (design pressure up to 16 bar) and temperatures up to 120 °C. It features a 4‑20 mA + HART output via an M20 electrical connector, LCD display, and a robust IP65 enclosure — ideal for industrial installations.
| Specification | Details |
|---|---|
| Brand | VACORDA |
| Product Type | Metal Rotor Flowmeter |
| Flow Direction | Left in → Right out |
| Media | Inert Gas |
| Fluid Density | 1.337 kg/m³ |
| Operating Pressure | Atmospheric |
| Design Pressure | Up to 16 bar |
| Temperature Range | 0–120 °C |
| Flow Rate | 0–280 Nm³/h |
| Process Connection | EN 1092‑1 DN 80 PN 16 RF, SS316L |
| Wetted / Body Material | SS316L |
| Output Signal | 4–20 mA with HART + LCD Display |
| Electrical Connector | M20 × 1.5 |
| Supply Voltage | 24 VDC |
| Accuracy | ± 1.5% |
| Protection Rating | IP65 |
