VERVO Reduced-Port Ball Valve 4×3″ – CS Body, 316 Trim, RPTFE Seat
$ 720
VERVO 4×3″ Ball Valve
-
2-way reduced-port design
-
WCB body with 316SS trim and RPTFE seats
-
RF flanged ends; 229 mm compact face-to-face
-
Graphite packing and stainless/graphite gasket for tight sealing
-
API 6D compliant for industrial applications
VERVO Reduced-Port Ball Valve 4×3″ – CS Body, 316 Trim, RPTFE Seat
Engineered to API 6D standards, this 4 × 3″ reduced-port 2-way ball valve delivers reliable flow control in industrial piping systems. Featuring a cast carbon steel WCB body paired with a 316 stainless steel trim and RPTFE seats, it ensures durability and excellent chemical resistance. The flange RF connection, graphite packing, and stainless steel/graphite SPW gasket offer leak-tight performance. Its compact 229 mm face-to-face design and bonnet style make it ideal for tight installations requiring robust, standardized valves.
| Specification | Details |
|---|---|
| Brand | VERVO |
| Product Type | Reduced-Port Ball Valve (2-Way) |
| Size (Inlet × Outlet) | 4″ × 3″ |
| Design Rating | 150 LB (ANSI) |
| Body Material | Carbon Steel A216-WCB |
| Trim Material | Stainless Steel 316 |
| Seat Material | RPTFE (Reinforced PTFE) |
| Connection Type | Flanged, Raised Face (RF) |
| Face-to-Face Length | 229 mm |
| Soft Goods | Graphite Packing; SS316 + Graphite Gasket |
| Port Type | Reduced Port |
| Standard | API 6D |
| Style | Bonnet |
