ABB DDS Top Performance Gauge Pressure Transmitter 266GST.F.K.B.N.A.D-EA.L1.B6.NM
$ 7,315Each
Unit : Each
Lead Time
TBD
Ex-Works
USA
Shipping
Standard domestic shipping within the USA at a flat rate of $50.
Get a quote for international shipment.
Key Features
-
High measurement accuracy suitable for critical pressure control applications
-
Corrosion-resistant Hastelloy diaphragm ensures long service life in harsh media
-
Digital 4-20 mA with HART communication enables advanced diagnostics and integration
-
Intrinsically safe design certified for hazardous area installations
-
Integral LCD and flexible mounting options simplify installation and local monitoring
ABB DDS Top Performance Gauge Pressure Transmitter 266GST.F.K.B.N.A.D-EA.L1.B6.NM
The ABB DDS Top Performance Gauge Pressure Transmitter is a high-accuracy industrial instrument engineered for precise gauge pressure measurement in demanding process environments. Designed for liquids, gases, and steam, this transmitter delivers exceptional measurement stability and long-term reliability. Its robust construction, advanced digital output, and intrinsic safety certification make it well suited for oil & gas, chemical processing, power generation, and general industrial automation applications.
Specifications
| Specification | Details |
|---|---|
| Manufacturer | ABB |
| Product Type | Gauge Pressure Transmitter (Top Performance) |
| Part Number | 266GST.F.K.B.N.A.D-EA.L1.B6.NM |
| Model | 266GST DDS Primary Unit |
| Function | High-precision gauge pressure measurement |
| Sensor Span Limits | 0.4 to 40 kPa (4–400 mbar / 1.6–160 in. H₂O) |
| Overpressure Rating | 1 MPa (10 bar / 145 psi) |
| Base Accuracy | ±0.06% of span |
| Diaphragm Material | Hastelloy C-276 |
| Fill Fluid | Silicone oil (NACE compliant) |
| Process Connection Material | AISI 316L Stainless Steel (1.4404) |
| Process Connection Type | 1/2-14 NPT Female (NACE) |
| Gasket Material | None |
| Housing Material | Aluminium alloy (barrel type) |
| Electrical Connection | 1/2-14 NPT |
| Output Signal | Digital diaphragm seal, 4-20 mA + HART |
| Explosion Protection | FM Intrinsic Safety approvals (USA & Canada) |
| Display | Integral LCD |
| Mounting Bracket | Pipe or wall mounting, carbon steel |
| Application | Industrial process pressure monitoring |
| Compatibility | HART-enabled control and automation systems |
| Mounting | Horizontal or vertical pipe and wall mounting |
