Coriolis Mass Flowmeter DN25 MTCMF-025
$ 2,320
Part No: MTCMF-025
-
Compact-type Coriolis flowmeter with stainless steel construction
-
Accurate measurement of flow, density, and temperature
-
DIN DN25 PN40 flange, supports 4–20mA, pulse, and RS485 output
-
Rated IP67 and explosion-proof for hazardous industrial environments
Description
Coriolis Mass Flowmeter DN25 MTCMF-025
The MTCMF-025 Coriolis Mass Flowmeter is a compact, high-accuracy instrument engineered for mass flow, temperature, and density measurement in industrial applications. Designed with a stainless steel SS316L measuring tube and SS304 housing, it ensures reliable performance in harsh environments. It supports multiple output signals and features explosion-proof protection suitable for hazardous areas.
| Specification | Details |
|---|---|
| Brand | – |
| Product Type | Coriolis Mass Flowmeter |
| Part Number | MTCMF-025 |
| Nominal Size | DN25 |
| Flow Range | 960 to 9600 kg/hr |
| Flange Standard | DIN flange DN25 PN40 |
| Measuring Tube Material | SS316L |
| Housing Material | SS304 |
| Structure | Compact type |
| Transmitter | FT-522 |
| Accuracy | 0.2% |
| Display Content | Total flow, flow rate, temperature, density |
| Output Signal | 4~20mA / Pulse / RS485 |
| Power Supply | 220 VAC or 24 VDC |
| Design Temperature | -50 to +200°C |
| Ambient Temperature | -20 to +60°C |
| Protection | IP67 |
| Cable Entry | M20×1.5 |
| Nominal Pressure | 0–4 MPa |
| Explosion-proof Level | Ex db ia ⅡC T6 Gb |
| Gross Weight | 40 kg |
| Dimensions (mm) | 700 × 640 × 340 |
