MVA 2-HANDLE MANIFOLDS MVA2SH2F WinSMARTâ„¢

$887.00

Part No: MVA2SH2F
MVA 2-HANDLE MANIFOLDS This 316 stainless steel manifold features a 2-handle system with flange-to-flange connections. Designed for harsh environments, it offers hard seat configuration and PTFE packing, rated for 10,000 psi, ideal for pressure transmitter systems in industrial applications.

Add to Wishlist
Add to Wishlist
Category:
Trust Badge Image

Description

MVA 2-HANDLE 316SS FLANGE x FLANGE, HARD, PTFE, 10,000 PSI

DESCRIPTION & FEATURES

  • Built for rugged environments with differential pressure transmitters and impulse lines.
  • Two-handle design with one isolation valve and one vent valve.
  • The isolation valve is positioned on top, while the block and bleed feature is located on the side in a 90-degree orientation.
  • Available in pipe-to-pipe, pipe-to-flange, and flange-to-flange configurations to suit various installation needs.
  • Constructed with multiple material variants to handle different media requirements.
  • Features soft and hard seat options with 6,000 psi and 10,000 psi pressure ratings.
  • PTFE packing is standard, with optional Graphoil available for enhanced sealing performance.
  • CRN available on request for Canadian compliance.
  • 5-year warranty ensures long-lasting reliability and performance.

APPLICATIONS

  • Optimized for use with Winters WinSMARTâ„¢ Series and compatible with other pressure transmitters, especially those using M10x45 bolts.
  • Essential for process and industrial environments where manifold systems are critical for maintenance, testing, and upgrading instruments.

SPECIFICATIONS

Feature Details
Part Number MVA2SH2F
Connection 1/2″ Female x Flange
Handles Straight or Angled
Material 316 Stainless Steel
Seat Type Hard Seat
Packing Material PTFE (Graphoil optional)
Max Pressure 10,000 psi
