Siemens SIMATIC CPU 1214C DC/DC/DC 14DI/10DO/2AI 6ES7214-1AG40-0XB0
$ 360
Lead Time: 1 Week
Ex-Works: Arizona USA
Shipping:
Standard domestic shipping within the USA at a flat rate of $50.
Get a quote for international shipment.
6ES7214-1AG40-0XB0
-
Siemens CPU 1214C, compact automation controller
-
14 digital inputs, 10 digital outputs, 2 analog inputs
-
High-speed pulse outputs and counting functions
-
Supports PROFINET, OPC UA, PROFIBUS, AS-Interface
-
Web server and advanced diagnostics
-
Memory: 150 kB work, 4 MB load, expandable via SIMATIC card
-
PID controller and positioning functions integrated
-
IP20, compact size: 110 × 100 × 75 mm, weight 415 g
Siemens SIMATIC CPU 1214C DC/DC/DC 14DI/10DO/2AI 6ES7214-1AG40-0XB0
The Siemens SIMATIC CPU 1214C DC/DC/DC (6ES7214-1AG40-0XB0) is a compact and highly flexible automation controller, ideal for small to medium-scale industrial applications. Featuring 14 digital inputs, 10 digital outputs, and 2 analog inputs, this CPU offers robust processing performance, extensive diagnostics, and multiple communication protocols including PROFINET, OPC UA, and PROFIBUS. It supports advanced functions like pulse train outputs, counters, frequency measurement, PID control, and positioning, making it suitable for a wide range of automation tasks.
Technical Specification
| Parameter | Specification |
|---|---|
| Product Type | CPU 1214C DC/DC/DC |
| Part Number / Model | 6ES7214-1AG40-0XB0 |
| Firmware Version | V4.7 |
| Programming Package | STEP 7 V20 or higher |
| Supply Voltage | 24 V DC (20.4–28.8 V) |
| Reverse Polarity Protection | Yes |
| Current Consumption | 500 mA CPU only, Max 1,500 mA with modules |
| Inrush Current | 12 A at 28.8 V |
| Power Loss | Typ. 12 W |
| Integrated Work Memory | 150 kB |
| Load Memory | 4 MB + SIMATIC Memory Card |
| Backup | Yes, maintenance-free, batteryless |
| Bit Processing Time | 0.08 μs/instruction |
| Word Processing Time | 1.7 μs/instruction |
| Floating Point Processing | 2.3 μs/instruction |
| Digital Inputs | 14; 6 HSC for high-speed counting |
| Digital Outputs | 10; 4 high-speed pulse outputs |
| Analog Inputs | 2 (0–10 V) |
| Analog Outputs | 0 |
| Output Voltage | Signal “1”: min. 20 V, Signal “0”: max. 0.1 V |
| Output Current | 0.5 A per channel |
| Switching Frequency | Pulse outputs: max 100 kHz |
| PROFINET IO Controller/Device | Yes |
| OPC UA Server | Yes (Basic license required) |
| Web Server | Yes |
| AS-Interface | Supported via CM1243-2 |
| Communication Protocols | TCP/IP, SNMP, DCP, LLDP, MODBUS |
| Number of PG/HMI/S7/Open User/Web Connections | 34 reserved / 68 max total |
| Counters | 6, max. 100 kHz |
| Position-Controlled Axes | 8 |
| PID Controller | Yes |
| Alarm Inputs | 4 |
| Pulse Outputs | 4 |
| Potential Separation | Digital outputs: Yes; digital inputs: No |
| EMC | IEC 61000-4-2, -4-4, -4-5, -4-6; EN 55011 Class A/B |
| IP Degree of Protection | IP20 |
| Environmental Product Declaration | Yes |
| Global Warming Potential | 111 kg CO₂ eq |
| Ambient Temperature | Operation: -20 to 60 °C, Storage: -40 to 70 °C |
| Dimensions (W×H×D) | 110 × 100 × 75 mm |
| Weight | 415 g |
